FR DPOX180H B 180MHz 2 IN 1 OSCILLOSCOPE

✅ FR DPOX180H – 180 MHz Handheld Oscilloscope & DDS Signal Generator

The FR DPOX180H is a portable, dual-channel digital phosphor oscilloscope with a built-in DDS signal generator. With 180 MHz bandwidth, 500 MS/s real-time sampling, and a sharp IPS display, it’s ideal for electronics repair, diagnostics, and embedded development.

🔧 Key Features

✅ Bandwidth: 180 MHz
⚡ Sampling Rate: 500 MS/s real-time
📊 Waveform Refresh Rate: Up to 50,000 wfm/s
🎛️ Signal Generator: 14 waveforms, up to 20 MHz sine
🔧 Trigger Modes: Auto, Normal, Single (with adaptive HF suppression)
📺 Display: 2.8″ IPS LCD, 320×240 resolution
💾 Memory Depth: 120kpts + waveform/screenshot storage
📐 Voltage Sensitivity: 5 mV/div to 10 V/div
🛡️ Input Protection: ±400 V max
⚙️ Extra Features: One-key Auto, FFT, zoom, save/recall, dual-channel view

🔧 Technical Specs

📐 Channels: 2
🕒 Rise Time: ~2.5 ns
🔌 Coupling: AC/DC
📏 Input Impedance: 1 MΩ ∥ 18 pF
⏱️ Time Base: 5 ns – 50 s/div
⚡ Max Input Voltage: ±400 V (with protection)
🔋 Battery: 3000 mAh, ~3.5 hours usage
🔌 Charging: USB-C 5V / 2A
📦 Dimensions: 142 × 92 × 39 mm
⚖️ Weight: ~285 g

📦 Package Includes

📦 1x FR DPOX180H Oscilloscope
📦 2x 200 MHz Probes
🔌 1x USB Charging Cable
📘 1x User Manual
🧊 1x Built-in Heat Sink (Aluminum)

🧠 Why Choose FR DPOX180H?

This 2-in-1 device combines an oscilloscope and waveform generator in one compact, professional-grade unit. Whether you're troubleshooting in the field or testing circuits on the bench, it delivers performance, portability, and value in a rugged handheld package.
