J5019 Li-ion Battery Charger and Boost Module 5V Output Micro USB

J5019 Li-ion Battery Charger + Boost Module – 5V Output with Micro USB

The J5019 is a compact all-in-one Li-ion battery charging and boost converter module. It combines a lithium battery charger (via micro USB input) with a built-in boost converter that outputs a stable 5V DC, making it ideal for building DIY power banks, portable devices, and battery-powered embedded systems.

The module allows simultaneous charging and discharging, enabling pass-through power operation for uninterrupted device use while the battery charges.

Key Specifications

• Model: J5019
• Input: Micro USB, 5V DC
• Charging Voltage: 4.2V (Li-ion / LiPo)
• Charging Current: Up to 1A
• Boost Output Voltage: 5V DC
• Boost Output Current: Up to 1A
• Battery Compatibility: 3.7V Li-ion / LiPo single cell
• Module Size: Compact PCB (approx. 34mm x 26mm)

Key Features

• 2-in-1: Li-ion charger + 5V boost converter on a single board
• Micro USB charging input for easy power connection
• Simultaneous charge and discharge (pass-through) support
• Overcharge, over-discharge, and short circuit protection
• LED indicators for charging and full charge status
• Solder pad connections for battery and output wiring
• Compact size suitable for embedded and wearable projects

Applications

• DIY power bank construction
• Portable Arduino and ESP8266/ESP32 projects
• Battery-powered IoT devices
• Wearable electronics
• Portable sensor nodes and data loggers
• Solar-powered embedded systems

Package Contents

• 1x J5019 Li-ion Charger + Boost Module
