RP2040 Microcontroller Development Board with Type-C USB

Experience the power of the Raspberry Pi RP2040 in a compact, breadboard-friendly form factor. This development board features a USB Type-C connector, castellated edges for SMD mounting, and gold-plated pads for reliable connections — ideal for advanced makers and embedded developers.

• MCU: Raspberry Pi RP2040 (dual-core ARM Cortex-M0+ @ 133MHz)
• Flash: 2MB onboard QSPI Flash
• RAM: 264KB SRAM
• USB: Type-C (USB 1.1 device & host)
• GPIO: 26 multi-function pins (D0–D13, A0–A3, B0–B1)
• Analog Inputs: 4 (12-bit ADC)
• Interfaces: SPI, I2C, UART, PWM, PIO
• Castellated edges for SMD soldering
• Gold-plated through-hole pads
• Onboard RST button
• Compatible with Arduino IDE, MicroPython, CircuitPython
