Sharp Distance Sensor 80cm GP2Y0A21YK0F

📏 Sharp GP2Y0A21YK0F Distance Sensor – Accurate Object Detection up to 80cm

The Sharp GP2Y0A21YK0F Infrared Distance Sensor is a highly reliable module designed for non-contact distance measurement. With a range of 10cm to 80cm, it’s ideal for robotics, obstacle avoidance, and object detection projects where precision and stability matter. 🤖📡

🔧 Key Features
📐 Model: GP2Y0A21YK0F
📏 Sensing Range: 10 cm – 80 cm
📟 Output: Analog Voltage (corresponds to distance)
⚡ Operating Voltage: 4.5V – 5.5V DC
🔌 Interface: 3-Pin (VCC, GND, OUT)
🎯 Stable Output with minimal noise and fast response
💡 Works in ambient light – reliable even in bright conditions

🧰 Package Includes
✅ 1x Sharp GP2Y0A21YK0F Distance Sensor Module
📄 Wires/connector may vary by version
🧰 Compatible with Arduino, ESP32, Raspberry Pi, and other microcontrollers

🧠 Perfect For
🚗 Obstacle-avoiding robots
📦 Object detection & sorting systems
🛠️ Industrial automation
🖥️ Touchless control panels
🎓 STEM and electronic learning kits

🛠️ How It Works
1️⃣ Sensor emits infrared light
2️⃣ Measures the angle of reflection from nearby object
3️⃣ Outputs analog voltage (higher voltage = closer object)
📊 Use ADC (Analog to Digital Conversion) to convert the signal into distance data

🧠 Pro Tip: Pair it with an OLED display or buzzer to build interactive and smart distance-alert systems!
