STM32F103C8T6 Development Board

🧠 STM32F103C8T6 Development Board – ARM Cortex-M3 Power for High-Performance Projects
The STM32F103C8T6 Development Board (commonly known as the "Blue Pill") is a compact, affordable, and powerful board based on the ARM Cortex-M3 processor. It offers 32-bit performance, low power usage, and high-speed I/O — ideal for robotics, automation, and IoT applications.

🔧 Key Features
🔹 Microcontroller: STM32F103C8T6 (ARM Cortex-M3 @ 72 MHz)
📦 Flash Memory: 64 KB
🧠 SRAM: 20 KB
📟 I/O Pins: 37 GPIOs with multifunction support
🌀 Interfaces: UART, SPI, I2C, CAN, PWM, ADC
⚡ Operating Voltage: 3.3V (5V tolerant I/Os)
🔌 Programming Options:
• SWD (Serial Wire Debug)
• USB to Serial (via external USB-TTL module)

🧰 Package Includes
✅ 1× STM32F103C8T6 “Blue Pill” Development Board
📄 Male header pins (may or may not be pre-soldered)
🧰 Fully compatible with: STM32CubeIDE, STM32duino (Arduino IDE), PlatformIO

🧠 Perfect For
🤖 Real-time robotics & automation systems
📲 Smart IoT device prototyping
🖥️ Embedded systems learning & experimentation
🚗 CAN-based automotive modules
🎓 Academic & engineering education

🛠️ How It Works
1️⃣ Write code using STM32CubeIDE, Arduino IDE, or PlatformIO
2️⃣ Upload firmware via USB-TTL adapter or ST-Link debugger
3️⃣ Connect peripherals: sensors, displays, motors, and communication modules with ease

💡 Pro Tip: Use with an ST-Link V2 debugger for fast, stable SWD programming and real-time debugging! 🛠️
