Waveshare RP2350-Zero Microcontroller Board (USB-C)

Waveshare RP2350-Zero Microcontroller Board

The Waveshare RP2350-Zero is an ultra-compact, high-performance microcontroller board powered by the Raspberry Pi RP2350 chip. Measuring just 23.5×18mm, it packs dual-core Cortex-M33 processing power into a tiny footprint — perfect for space-constrained embedded projects, wearables, and advanced IoT applications.

Key Features

• Raspberry Pi RP2350 dual-core Cortex-M33 @ 150MHz
• USB Type-C connector for power and programming
• BOOT and RUN buttons onboard
• 30 GPIO pins (castellated + through-hole)
• 520KB SRAM + 2MB onboard Flash
• Supports MicroPython, CircuitPython, and C/C++ SDK
• Ultra-compact form factor: 23.5 × 18mm

Specifications

• MCU: Raspberry Pi RP2350
• Core: Dual-core ARM Cortex-M33
• Clock Speed: Up to 150MHz
• Flash: 2MB
• SRAM: 520KB
• USB: Type-C (USB 1.1)
• GPIO: 30 pins
• Dimensions: 23.5 × 18mm

Applications

• Embedded systems and IoT projects
• Wearable electronics
• Robotics and automation
• MicroPython / CircuitPython development
• USB HID and peripheral devices
